제품 세부 정보
원래 장소: 후베이, 중국
브랜드 이름: KAEMI or GM
지불 및 배송 조건
가격: $2,960.00/sets
조건: |
새로운 |
적용 가능한 산업: |
호텔, 의류 매장, 제조 공장, 기계 수리 매장, 가정용, 소매, 인쇄 매장, 광고 회사, 신발/모자/가방/가구/자동차 인테리어 생산 |
무게 (kg): |
400 |
전시실 위치: |
베트남 |
비디오 출입 검사: |
제공 |
기계 시험 보고: |
제공 |
판매 유형: |
새로운 제품 2020 |
핵심 부품에 대한 보증: |
2년 |
핵심 부품: |
엔진, 모터, 드라이버 및 마더보드 |
보증: |
1년, 전체 기계에 대해 |
제품 이름: |
좋은 값싸고 사용 된 중고 평면 템플릿 보드 밀링 커터 |
절단기 프레임 및 케이스: |
블루 프레임+실버 케이스 |
기계 물질: |
모든 알루미늄 조리대 |
자르는 소재: |
PVC, PP, POM, 아크릴, PET, Kraft 등 |
절단 도구: |
밀 커터, 조각가, 드릴러, 펜 |
절단 범위: |
1500*900mm |
두께를 줄이기: |
≤1.5mm-6.0mm |
절단 속도: |
500~1800mm/초 |
절단기 크기: |
1900*1450*1100mm |
적용 가능한 분야 또는 산업: |
의류, 가방, 핸드백, 가구, 자동차 장식, 종이 상자 |
조건: |
새로운 |
적용 가능한 산업: |
호텔, 의류 매장, 제조 공장, 기계 수리 매장, 가정용, 소매, 인쇄 매장, 광고 회사, 신발/모자/가방/가구/자동차 인테리어 생산 |
무게 (kg): |
400 |
전시실 위치: |
베트남 |
비디오 출입 검사: |
제공 |
기계 시험 보고: |
제공 |
판매 유형: |
새로운 제품 2020 |
핵심 부품에 대한 보증: |
2년 |
핵심 부품: |
엔진, 모터, 드라이버 및 마더보드 |
보증: |
1년, 전체 기계에 대해 |
제품 이름: |
좋은 값싸고 사용 된 중고 평면 템플릿 보드 밀링 커터 |
절단기 프레임 및 케이스: |
블루 프레임+실버 케이스 |
기계 물질: |
모든 알루미늄 조리대 |
자르는 소재: |
PVC, PP, POM, 아크릴, PET, Kraft 등 |
절단 도구: |
밀 커터, 조각가, 드릴러, 펜 |
절단 범위: |
1500*900mm |
두께를 줄이기: |
≤1.5mm-6.0mm |
절단 속도: |
500~1800mm/초 |
절단기 크기: |
1900*1450*1100mm |
적용 가능한 분야 또는 산업: |
의류, 가방, 핸드백, 가구, 자동차 장식, 종이 상자 |
Main Features
1. Pneumatic Fixation Technology of High Efficiency Template
2.Integrated Floating Pressure Foot and Vacuum Cleaning Technology
3.Flexible Modification System for Cutting Starting Points and Cutting Sequence
4.Independent Templates Editing and Designing System
Model | GM-1509M2 GM1812M3 |
Cutting Window(Fabric Scope) | 1500*900mm 1800*1200mm |
Overall Dimension(mm) | 1900*1450*1100 2200*1750*1100 |
Product Features | Compatible with various CAD softwares;Design while the machine is cutting |
Cutting Speed | 500-1500mm/s |
Cutting Thickness | ≤1.5mm-6.0mm |
Cutting Materials | PVC, PP,POM,Acrylic, PET, Kraft, etc |
Processing Methods | Mill, Cut, Drill, Plot |
Cut Tools | Mill-cutter, Graver, Driller, Pen |
Repeatability Precision | ≤0.01mm |
Software Resolution | 0.025mm/0.01mm/0.1mm(Optional) |
Communication Port | USB/RJ45 Ethernet |
Buffer Memory Size | 1M/8M/32M(Can butter more than 1 page) |
File Formats | DXF/HPGL/GPGL/PLT Formats Compatible |
Control Panel | 9 Keys and LED Display |
Driver System | Moons Motor driver; High-accuracy Lead Rail, Double Lead Rail on crossbeam |
Supply Voltage | AC 220V/110V±10%, 50Hz/3.5KW |
Fuse Value | 30A/35A |
Working Environment | -30~55℃ or -22~131℉ |
Fasten | Vacuum/Clamping |
Mill Motor | 800W/1500W, Water-cooling/Air-cooling, 5000~240000 RPM Inverter |
Waste Elimination | 220V/1.4KW, Industrial 15L Vacuum Cleaner |
Since its establishment, GEMEI has developed a series of cutting machines for clothing, bags, shoes and hats, and obtained a number of software copyright and patent certificates. Based on the profound understanding of China’s garment, luggage and footwear industry, GM series of cutting machine combines the essence of Chinese and foreign technologies, closely combines the advantages of the world's advanced technology and Chinese manufacturing industry, adopts a novel design different from the domestic traditional cutting machine, and fully experiences the design principle of "good at core, simple in shape". After the first continuous drum cutter came into being in the middle part of China , we successively developed the sample cutter for the luggage industry and continuous cutting garment sample cutter.
"The competition of enterprises is the competition of talents." GEMEI firmly grasps the trend that the world manufacturing
industry is transferring to the middle part of the world, and has established a research and development team composed of doctors and senior engineers and other high-quality talents,and insists that "innovation" is the eternal power of the development of GEMEI.
1. Q: Are you a manufacturer?
A: Yes, we are specializing in the r&d production for template cutter/inkjet cutter/pen writing cutter/cnc digital fabric cutter/graph plotter in this field for 10 years.
2. Q: How do you pack these products?
A: Usually packed in wooden case and can pack according to export standard or your requirement.
3. Q: Is it customizable?
A: Yes, We have basic sizes commonly applied in the field and can customize according to your requirements.
4.Q: After-sales service
A: Yes, professional after-sales team and 24-hour technical support by phone, email or skype
5.Q: What is your lead time?
A: Spot goods usually take 2-4 days, and customization takes 5-7 days
